USB2.0 to SATA and EIDE ATA Bridge Adapter / Converter Cable for Sata and IDE Hard Drives
Color: Black Size\Length: Adapter Part No.CGFUBCP
New Design True Hot-plug and Hot-Swap USB 2.0 Adapter with 2Amp Power Supply, Great Test Bench Device. Converter for EIDE ATA-66/100/133 and SATA/SATA II HDD, conect any SATA/PATA Device to your USB 2.0 Port!
CHIPSET: Jmicron-JM20339 Single Chip Ultra Fast Solution
USB 2.0 Adapter to any Native SATA 3.5' / SATA II 3.5' / IDE ATA-66 / IDE ATA-100 / IDE ATA-133 /2.5 inch, 3.5 inch and 5.25 Inch Optical Drives Supported.
Drive from 40GB up to 7500GB.
Compatible with Windows ME/2000/XP/2003.Works with MAC OS X.3.6 or Greater!
Adapter plugs directly to your usb 2.0 port on a windows based computer and provides one SATA Signal/Power port one IDE 44-Pin Port and One IDE 40-Pin Port to connect directly into your 5.25 inch, 3.5inch or 2.5inch HDD.
Uses Jmicron Chip for Conversion. Tested with WD/Maxtor/Seagate/Hitachi SATA drives.
Package includes Adapter cable and one DC 2AMP Power Adapter provides external power to your drive.
Convert 2.5"/3.5" Serial ATA HDD and 5.25" Serial ATA Devices into USB2.0 interface
Convert 2.5"/3.5" IDE HDD and 5.25" IDE Devices into USB2.0 interface
Max tranfer speed 480Mb/s
Power adapter for 3.5"/5.25" devices; Bus-Power for 2.5" HDD
User Guide NEW ULTRA FAST CHIP and UL and FCC Approved HIGH-Output Power Adapter JM20337 IDE and SATA to USB chip with Back-Up software and single Button Back-Up Activation Feature. Convert 2.5"/3.5" Serial ATA HDD and 5.25" Serial ATA Devices into USB2.0 interface Convert 2.5"/3.5" IDE HDD and 5.25" IDE Devices into USB2.0 interface Max tranfer speed 480Mb/s Power adapter for 3.5"/5.25" devices; Bus-Power for 2.5" HDD
TECH NOTES: USB 2.0 to SATA/IDE Converter Enable you to connect your SATA or IDE devices to any PC, Mac, or laptop with USB 1.1 & USB 2.0 port Fast and easy installation Supports both 3.5" (regular desktop HDDs) and 2.5" (laptop used HDDs) SATA & IDE/ATA drives Supports hard disk drive size at 750GB and higher
HOT-PLUG AND HOT-SWAP MODEL USB to SATA HDD ADAPTER WITH QUICK SWAP
Connect black USB plug to USB port on computer.
