9 Port USB 3.2 Gen 1 Hub w/ Integrated DIN-Rail Clip

Model No. CG-9U3PL

+7~36V DC Input | Surface Mountable | DIN Rail | 5 Gbps | LED Power Indicator

Expand 1 USB port into 9 USB ports for your host system
Supports USB 3.2 Gen 1 5Gbps, USB 2.0 480 Mbps, USB 1.1 1.5 Mbps data rates
High-quality switching power supply for reliable performance
Plug-and-play functionality with no driver or software installation required
Integrated DIN-Rail Clip for easy and secure mounting in industrial environments.
Upstream: 1 USB port, Type B connector
Downstream: 9 USB ports, Type A connectors
Power Connector: 3-Pin Terminal Block
Mounting Options: Wall, Surface, and DIN Rail
Supply Current: 900mA USB for Each Down-stream Port

$97.49

Model No. CG-9U3PL

In stock

Export Product as PDF

Need some help? Contact us.

Product Documents

CG-9U3PL - Technical Data Sheet

Quick Links:

Description

Introduction:

Experience unparalleled connectivity with our 9 Port USB 3.2 Gen 1 Hub featuring an integrated DIN-Rail Clip. This industrial-grade hub effortlessly transforms one USB port into nine high-speed USB 3.2 Gen 1 ports, supporting data rates of up to 5Gbps for seamless connectivity. Powered by a top-tier industrial-grade switching power supply, it delivers a robust 900mA current to downstream devices. The hub requires no driver or software installation, making it a hassle-free solution for expanding your device connectivity. With the integrated DIN-Rail Clip, this hub is not only powerful but also conveniently mountable in industrial settings. Upgrade your connectivity game with this reliable and efficient USB hub.

Features:

Supports USB 3.2 Gen 1 (5Gbps), USB 2.0 (480Mbps), USB 1.1 (1.5Mbps) data rates
High-quality switching power supply for reliable performance
Up to 900mA current to downstream devices
Multiple transaction translator (TT) architecture to each USB downstream port
LED indicator for power status
Support USB Battery Charging: SDP, CDP modes
Item Dimensions: 130mm(L) x 100mm(W) x 32mm(H)
Plug-and-play functionality with no driver or software installation required
Integrated DIN-Rail Clip for easy and secure mounting in industrial environments
CE, FCC approval

Package Contents:

9 Port USB 3.2 Gen 1 Hub
1.5m USB 3.1 A to B cable
3 Pin Terminal Block

Specifications

Product Specifications

Power

Input Voltage	+7~36V DC
Power Source	3-Pin Terminal Block
Charging Protocols	BC 1.2, Charging Downstream Port (CDP), Standard Downstream Port (SDP)
Per USB Port Current	900mA maximum

Compliance

Certifications

CE, FCC, RoHS, TAA

Physical Characteristics

Color	Gray
Item Dimensions (L × W × H)	5.25 × 4 × 1.25 in
Item Weight	0.41 lbs.
Mounting Style	Din-Rail Mount, Surface Mount, Wall Mount
Material of Construction	Plastic

Environmental

Operating Temperature	0°C to 70°C (32°F to 158°F)
Storage Temperature	-20 to 75°C (-4 to 167°F)
Humidity	5% ~ 95% (non-condensing)

Product Information

Warranty

1 year from date of purchase

Hardware

Chipset	GL 3523
LED Indicators	Power
Downstream USB Ports	9 Type-A Female USB
Upstream USB Ports	1 Type-B Female USB

Performance & Safety

Max Data Transfer Rate

5Gbps

Other Data

UPC	045079164208
USB Interface	USB 3.2 Gen 1
Connector	3-Pin Terminal Block, USB Type-A Female, USB Type-B Female
Weight	0.72 lbs
Dimensions	6.25 × 5.25 × 2 in
